Description
| Particulars | Working Stoke | Admit in Columns X Job Heigh | CrossSlide Face) | Piller Face | V to V Centre (in Bed) | Bed Width | Bed Length | Table Width | Milling Head (ONE NO.) |
| 8'x4'x4' | 8' | 48"x48" | 16 | 14" | 24" | 30" | 15" | 36" | 5 H.P |
| 8'x5'x5' | 8' | 60"x60" | 20" | 18" | 30" | 36" | 15" | 42" | 5 H.P |
| 10'x4'x4' | 10' | 48"x48" | 16" | 14" | 24" | 30" | 18' | 36" | 5 H.P |
| 10'x5'x5' | 10' | 60"x60" | 20" | 18" | 30" | 18" | 42" | 20" | 5 H.P |
| 12'x4'x4' | 12" | 48"x48" | 16" | 14" | 24" | 30" | 21' | 36" | 5 H.P |
| 12'x5'x5' | 12' | 60"x60" | 20" | 18" | 30" | 36" | 21' | 42" | 5 H.P |
| 12'x6'x6' | 12' | 72"x72" | 24" | 20" | 30" | 36" | 21' | 42" | 7.5 H.P |
| 14'x7'x6' | 14' | 84"x72" | 24" | 20" | 30" | 36" | 24' | 42" | 7.5 H.P |
| 16'x5'x5' | 16' | 60"x60" | 20" | 18" | 30" | 36" | 27' | 42" | 7.5 H.P |
| 16'x6'x6' | 16' | 60"x60" | 24" | 20" | 30" | 36" | 27' | 42" | 7.5 H.P |
| 16'x8'x6' | 16' | 96"x72" | 28" | 24" | 48" | 56" | 27' | 62" | 10 H.P |
| 20'x5'x5' | 20' | 60"x60" | 20" | 18" | 30" | 36" | 33' | 42" | 7.5 H.P |
| 20'x6'x6' | 20' | 72"x72" | 24" | 20" | 30" | 36" | 33' | 42" | 7.5 H.P |
| 20'x8'x6' | 20' | 96" x 72" | 28" | 24" | 48" | 56" | 33" | 62" | 10 H.P |
| 20'x10'x6' | 20' | 120"x72" | 30" | 24" | 60" | 72" | 33' | 96" | 15 H.P |
| 22'x6'x6' | 22' | 72"x72" | 24" | 20" | 30" | 36" | 36" | 42" | |
| 24'x8'x6' | 24' | 96"x72" | 28" | 24" | 48" | 56" | 39' | 62" | 10 H.P |
| 26'x10'x6' | 26' | 120"x72" | 30" | 24" | 60" | 72" | 42' | 96" | 15 H.P |
Standard Accessories
- Automatic Lubrication to ‘v’ guides.
- Provided with automatic lifting arrangement for easy and quick movement of cross slide.
- Single Millin Head on cross Slide.
- Equipped with electric panel and motor.
Special Accessories
- Extra Milling Head, Fead Gear Box
